Yokogawa S9681DB-0 Digital Oscilloscope

Description

The Yokogawa S9681DB-0 is a high-performance digital oscilloscope designed for demanding applications in electronics, telecommunications, and research and development. It offers advanced features to capture and analyze high-speed signals accurately.

Key Features

• Bandwidth: Supports up to 2 GHz bandwidth, enabling the capture and analysis of high-speed signals.
• Memory Depth: With a memory depth of up to 2 Mbytes, it captures long waveforms efficiently.
• Sample Rate: 5 GSa/s.
• Number of Channels: 4.
• Vertical Resolution: 10 bits.
• Horizontal Resolution: 2.5 ns/div.
• Time Base Range: 5 ns/div to 10 s/div.
• Trigger Types: Edge, pulse width, delay, video, and more.
• Measurement Functions: Voltage, current, time, frequency, and more.

Specifications

• Dimensions: 300 x 250 x 80 mm.
• Weight: 3 kg.
