Yokogawa NFDV151-P10 Digital I/O Module

Specifications

• Model: NFDV151-P10
• Number of Input Channels: 32
• Rated Input Voltage: 24 V DC
• Input ON Voltage: 18 to 26.4 V DC
• Input OFF Voltage: 5.0 V DC or less
• Input Current (at Rated Input Voltage): 4.1 mA ±20% per channel
• Instantaneous Allowable Maximum Input Voltage: 30.0 V DC
• Withstanding Voltage:
  • Between Input Signal and System: 2000 V AC for 1 minute
  • Between Commons: 500 V AC for 1 minute, common minus (-) side every 16-channel
• Functions:
  • Status Input
  • Push Button Input
  • Function for Detecting ON/OFF Status
  • Function for Counting the Push Button Edge
• Input Response Time: 8 ms or less (for status input)
• Minimum ON Detection Time: 20 ms (for push button input)
• Maximum ON/OFF Cycle: 25 Hz (for push button input)
• Maximum Current Consumption: 500 mA (5 V DC)
• Weight: 0.3 kg
• External Connection: Pressure Clamp Terminal, MIL Connector Cable
