Yokogawa AAM51 Current Voltage Output Module

Description:

The AMM51 is a versatile current and voltage output module designed for use in industrial automation systems. It provides precise control over field devices by delivering 4-20 mA current or voltage output, offering flexibility for a range of industrial applications.

Specifications:

• Model: AMM51
• Type: Current Voltage Output Module
• Rated Output Range: 4 to 20 mA DC
• Output Voltage Limit: 25.5 V DC or lower
• Data Update Period:
  • For A2SAM505 alone: 2 ms
  • For step response: 22 ms
• Current Consumption:
  • For 24 V DC system power supply: 38 mA or lower (24.0 V DC)
  • For 5 V DC internal power supply: 10 mA or lower (5.0 V DC)
• Withstanding Voltage: 1500 V AC for 1 minute, 42 V DC between field and system
• Mounting: Mounted on the nest for I/O adaptor (A2BA3D)
• Output Signal Setting: Output signals and ranges are configured via software
• Shipping Weight: 1 Kg
