Woodward 9907-166 Digital Turbine Control Module

Technical Specifications

• Dimensions: 14L x 11H x 4D inches
• Enclosure Type: Optional NEMA 4
• Features:
  • 2 Modbus (ASCII or RTU) Communication Ports
• Input Options:
  • 2 MPUs
  • 16 Contact Inputs
  • 6 Programmable Current Inputs
• Input Voltage:
  • 90–150 Vdc
  • 88–132 Vac (47–63 Hz)
• Keypad/Display: 30 Keys
• Manufacturer: Woodward
• Operating Temperature:
  • Without NEMA 4X: –25 to +65°C
  • With NEMA 4X: Up to 55°C
• Output Type:
  • 2 Actuator Outputs
  • 8 Relay Outputs
  • 6 Programmable Current Outputs
• Resolution: 2 Line LED - 24 Characters
• Standards:
  • Humidity and Vibration: Lloyd’s ENV2 test #1
• Weight: 9.11 lbs
