Woodward 5501-470 MicroNet Simplex LV Controller

Specifications:

• Model: 5501-470
• Type: Digital Microprocessor Controller Memory Module
• Manufacturer: Woodward
• Input Voltage: 24 VDC
• Output Voltage: 0-10 VDC
• Control Range: 0-100%
• Communication Interface: RS485
• Operating Temperature: -40°C to 85°C
• Dimensions: 100mm x 100mm x 25mm
• Country of Manufacture: United States (USA)

 Description:

The Woodward 5501-470 is a high-performance control system primarily designed for gas turbines, with applications in industrial and power generation settings. It provides precise control and monitoring capabilities, ensuring efficient and reliable operation. The control signal output from the Woodward 505 is converted into a hydraulic signal by the I/H converter, regulating the opening of the main steam door of the steam turbine compressor to control the turbine compressor speed.

Features:

• High-Speed Data Transmission:

  The 5501-470 module’s bus receiver/driver communicates with the VME bus, exchanging control, data, and address information.

• Parallel Interface:

  Utilizes high-speed, differential line drivers operating at VME transmission rate.

• Cable Interface:

  Equipped with a 100-pin metal shell Micro-D connector for cable connectivity.
