WAGO 750-554 Analog Output Module 750 Series

Brand:	WAGO	Item No:	750-554
Type:	PLC	Warranty:	1 year
Service:	One Year Warranty	Quality:	100% New And Origin
Delivery Time:	1-3 Days	Condition:	In Stock
Product information:	WAGO 750-554 Analog Output Module PLC This analog output module generates standard 4–20 mA signals. The output signal is electrically isolated and transmitted with a resolution of 12 bits. Power is derived from the field side.



Number of analog outputs 2
Total number of channels (module) 2
Signal type Current
Signal type (current) 4 … 20 mADC
Actuator connection 2 x (2-wire)
Resolution [bit] 12Bit
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Load impedance (current output) ≤ 600 Ω
Conversion time (typ.) 2ms
Measurement error (reference temperature) 25°C
Measurement error, deviation (max.) from the upper-range value 0.10%
Temperature error (max.) of the upper-range value 0.015%/K
Output error, reference temperature
Output error, deviation (max.) of the upper-range value 0.10%
Temperature error (max.) of the output range value 0.015%/K
Linearity ±10 µA
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 70mA
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission (supply voltage field side only) via spring contact)
Isolation 500 V system/field
Indicators LED (A, C) green: Function AO 1, AO 2
Number of incoming power jumper contacts 2
Number of outgoing power jumper contacts 2
