WAGO 750-480 2-channel Analog Input Module 750 Series

Brand:	WAGO	Item No:	750-480
Type:	PLC	Warranty:	1 year
Service:	One Year Warranty	Quality:	100% New And Origin
Delivery Time:	1-3 Days	Condition:	In Stock
Product information:	This 2-channel analog input module processes differential signals ranging from 0 to 20 mA. The input signal of each channel is electrically isolated and is transmitted with a resolution of 13 bits. The system supply powers the module. The shield directly connects to the DIN-rail. Measured value acquisition: Time synchronous within the module Measurement range overflow/underflow: Status byte and LED Conversion method: SAR (Successive Approximation Register) Operating mode: Continuously sampling (default) Protection: Non-linear limiting



Number of analog inputs 2
Total number of channels (module) 2
Signal type Current
Signal type (current) 0 … 20 mADC
Sensor connection 2 x (2-wire)
Input filter Low pass (1st order), fG = 5 kHz
Signal characteristics Differential
Resolution [bit] 13Bit
Operating mode Continuously sampling (default)
Input resistance (max.) 270Ω
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Protection Non-linear limiting
Admissible continuous overload 30V
Crosstalk attenuation 80dB
Monotonicity without error code yes
Measurement error (reference temperature) 25°C
Measurement error, deviation (max.) from the upper-range value 0.05%
Measurement error over entire temperature range ≤ 0.4 %
Temperature error (max.) of the upper-range value 0.01%/K
Sampling duration 5µs
Sampling delay (channel/channel) 1µs
Sampling delay (module) 1ms
Sampling repetition time 1ms
Measurement range overflow/underflow Status byte and LED
Measured value acquisition Time synchronous within the module
Value of the least significant bit (LSB) 2.4 µA
Conversion method SAR (Successive Approximation Register)
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 80mA
Isolation 500 V system/field or channel/channel
Indicators LED (A, C) green: Function AI 1, AI 2; LED (B, D) red: Error AI 1, AI 2
