WAGO 750-478 Input Module Analog 750 Series

 Number of analog inputs:  2
Total number of channels (module) 2
Signal type Voltage
Signal type (voltage) 0 … 10 VDC
Sensor connection 2 x (2-wire)
Input filter frequency (analog) 50Hz
Input voltage (max.) 24 V
Signal characteristics Single-ended
Resolution [bit] 16Bit
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Noise rejection at sampling frequency -100dB
Noise rejection above sampling frequency -40dB
Internal resistance 130kΩ
Conversion time (typ.) 80ms
Measurement error (reference temperature) 25°C
Measurement error, deviation (max.) from the upper-range value 0.10%
Temperature error (max.) of the upper-range value 0.01%/K
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 75mA
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission (supply voltage field side only) via spring contact)
Isolation 500 V system/field
Indicators LED (A, C) green: Function AI 1, AI 2; LED (B, D) red: Error AI 1, AI 2
Number of incoming power jumper contacts 2
Number of outgoing power jumper contacts 2

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone enquire from us,pls click this sales7@cambia.cn


Q&A

Q: Do you provide warranty for the goods?
A: Yes, we provide warranty for all the goods from us.

Q: Could you provide technology support?
A: We're in this field more than 12 years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.

Q: Do you keeps goods in stock or only trading?
A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.

Q: Does your goods are new and original ?
A: yes ,they are new and original.

❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍✨
