WAGO 750-476 Analog Input Module 750 Series

Brand:	WAGO	Item No:	750-476
Type:	PLC	Warranty:	1 year
Service:	One Year Warranty	Quality:	100% New And Origin
Delivery Time:	1-3 Days	Condition:	In Stock
Product information:	This analog input module processes standard ±10 V signals. The input signal is electrically isolated and is transmitted with a resolution of 16 bits. The internal system supply powers the module. The input channels of the module have a common ground potential. The 24 V supply is derived from the power jumper contacts. The shield directly connects to the DIN-rail.



Number of analog inputs 2
Total number of channels (module) 2
Signal type Voltage
Signal type (voltage) -10 … +10 VDC
Sensor connection 2 x (2-wire)
Input filter frequency (analog) 50Hz
Input voltage (max.) 24 V
Signal characteristics Single-ended
Resolution [bit] 16Bit
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Noise rejection at sampling frequency -100dB
Noise rejection above sampling frequency -40dB
Internal resistance 130kΩ
Conversion time (typ.) 80ms
Measurement error (reference temperature) 25°C
Measurement error, deviation (max.) from the upper-range value 0.1%
Temperature error (max.) of the upper-range value 0.01%/K
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 75mA
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission (supply voltage field side only) via spring contact)
Isolation 500 V system/field
Indicators LED (A, C) green: Function AI 1, AI 2; LED (B, D) red: Error AI 1, AI 2
Number of incoming power jumper contacts 2
Number of outgoing power jumper contacts 2

NEW AND ORIGIN ITEM IN STOCK



WITH ONE YEAR WARRANTY
