WAGO 750-475 Analog Input Module 750 Series

Brand:	WAGO	Item No:	750-475
Type:	PLC	Warranty:	1 year
Service:	One Year Warranty	Quality:	100% New And Origin
Delivery Time:	1-3 Days	Condition:	In Stock
Product information:	The analog input module processes AC and DC currents within a range of 0 to 1A (rms). The module measures the rms value of the current and displays it with a resolution of 100µA. The maximum current must not exceed 2A. The differential inputs are electrically isolated. The fieldside and internal system are electrically isolated. System voltage is used for voltage supply. The input channels are differential inputs. The shield (screen) is directly connected to the DIN rail.



Number of analog inputs 2
Total number of channels (module) 2
Signal type Current
Signal type (current) 0 … 1 AAC/DC
Sensor connection 2 x (2-wire)
Input voltage (max.) 24 VAC/DC (-20 … +20 %)
Signal characteristics Differential
Resolution [bit] 15Bit
Input resistance (max.) 0.022Ω
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Conversion time (typ.) 200ms
Measurement error (reference temperature) 25°C
Measurement error, deviation (max.) from the upper-range value 0.1%
Measurement error over entire temperature range ≤ ± 0.6 % of the full scale value
Temperature coefficient < ± 110 ppm / K of the full scale value
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 80mA
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission (supply voltage field side only) via spring contact)
Process data 0.0 A is 0x0000; 2.0 A DC is 0x4E20
Isolation 500 V system/field or channel/channel
Indicators LED (A, C) green: Function AI 1, AI 2; LED (B, D) red: Error AI 1, AI 2
Number of incoming power jumper contacts 2
Number of outgoing power jumper contacts 2
