WAGO 750-474 Analog Input Module 750 Series

Brand:	WAGO	Item No:	750-474
Type:	PLC	Warranty:	1 year
Service:	One Year Warranty	Quality:	100% New And Origin
Delivery Time:	1-3 Days	Condition:	In Stock
Product information:	This analog input module powers field-side signal conditioners and transmits electrically isolated analog signals to the bus system. The 24 V field supply is derived from the module's power jumper contacts. The shield directly connects to the DIN-rail. At approximately 25 mA, overload protection switches the measurement input to a high-resistance state. Once normal operating conditions resume, the measurement input will automatically switch back. This module powers 2-wire signal conditioners without dedicated power supply.



Number of analog inputs 2
Total number of channels (module) 2
Signal type Current
Signal type (current) 4 … 20 mADC
Sensor connection 2 x (2-wire, 3-wire)
Input filter frequency (analog) 50Hz
Input voltage (max.) 24 V
Input voltage (note) Non-linear, overload protected U = 1.2 V + 160 Ω x I meas
Signal characteristics Single-ended
Resolution [bit] 15Bit
Input resistance (max.) 220Ω
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Overvoltage protection 30 V, reverse polarity protected
Noise rejection at sampling frequency -100dB
Noise rejection above sampling frequency -40dB
Conversion time (typ.) 80ms
Measurement error (reference temperature) 25°C
Measurement error, deviation (max.) from the upper-range value 0.1%
Temperature error (max.) of the upper-range value 0.01%/K
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 75mA
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission (supply voltage field side only) via spring contact)
Isolation 500 V system/field
Indicators LED (A, C) green: Function AI 1, AI 2; LED (B, D) red: Error AI 1, AI 2
Number of incoming power jumper contacts 2
Number of outgoing power jumper contacts 2

NEW AND ORIGIN ITEM IN STOCK



WITH ONE YEAR WARRANTY
