WAGO 750-471 Analog Input Module 750 Series

Brand:	WAGO	Item No:	750-471
Type:	PLC	Warranty:	1 year
Service:	One Year Warranty	Quality:	100% New And Origin
Delivery Time:	1-3 Days	Condition:	In Stock
Product information:	This analog input module processes both voltage and current differential signals. 0 … 20 mA, 4 … 20 mA, 3.6 … 21 mA NE43, ±20 mA, 0 … 10 V, ±10 V, ±200 mV Channel-wise parameterizable measurement ranges Electrically isolated channels 16-bit resolution A wire break, overload or out-of-measurement range are indicated channel by channel via red LED depending on the set measurement range. The module can be configured via GSD file, e!COCKPIT and WAGO-I/O-CHECK.



Number of analog inputs 4
Total number of channels (module) 4
Signal type Voltage
Current
Signal type (current) 0 … 20 mADC; 4 … 20 mADC; 3.6 … 21 mADC; -20 … +20 mADC
Signal type (voltage) 0 … 10 VDC; -10 … +10 VDC; -0.2 … +0.2 VDC
Signal type (configurable) yes
Sensor connection 4 x (2-wire)
Input filter 50 Hz; 60 Hz; filter off
Input voltage (max.) 31.2 VDC
Signal characteristics Differential
Diagnostics Measurement range overflow/underflow; wire break in operating mode 4 … 20 mA and 3.6 … 21 mA NE43; overload in operating mode 0 … 20 mA, 4 … 20 mA, ±20 mA, 3.6 … 21 mA NE43
Resolution [bit] 16Bit
Input resistance (max.) 120Ω
Data width 4 x 16-bit data; 4 x 8-bit control/status (optional)
Internal resistance 100kΩ
Conversion time (typ.) 10ms
Conversion time Exception: The ±200 mV measurement range has a conversion time of 10 s and is therefore only suitable for slow systems.
Reference for measurement error Input ranges
Measurement error (reference temperature) 25°C
Measurement error, deviation (max.) from the upper-range value 0.1%
Reference for measurement error (2) ±200 mV
Measurement error, reference temperature (2) 25°C
Measurement error, deviation (max.) of the upper-range value (2) 0.3%
Temperature error (max.) of the upper-range value 0.01%/K
Configuration options WAGO-I/O-CHECK
CODESYS Library
e!COCKPIT
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 100mA
Supply voltage (field) 24 VDC; via power jumper contacts (power supply via blade contact; transmission (supply voltage field side only) via spring contact)
Isolation Functional insulation: 2000 VDC system/channel; 2000 VDC channel/channel
Indicators LED (A-D) green: Function AI 1 … AI 4; LED (E-H) red: Error AI 1 … AI 4
Number of incoming power jumper contacts 2
Number of outgoing power jumper contacts 2
Current carrying capacity (power jumper contacts) 10A
