WAGO 750-469 Analog Input Module 750 Series

Brand:	WAGO	Item No:	750-469
Type:	PLC	Warranty:	1 year
Service:	One Year Warranty	Quality:	100% New And Origin
Delivery Time:	1-3 Days	Condition:	In Stock
Product information:	This analog input module directly connects to two thermocouples. Internal electrical isolation allows operation of grounded sensors. The module automatically linearizes the entire temperature range. Cold junction compensation mitigates the clamping unit offset voltage over the 0–55°C operating range. A line break is indicated by a red LED. A green LED indicates readiness for operation and error-free communication with the coupler. The shield directly connects to the DIN-rail.



Number of analog inputs 2
Total number of channels (module) 2
Signal type Thermocouple
Sensor connection 2 x (2-wire)
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Internal resistance 1000kΩ
Resolution (over entire range) 0.1 °C
Conversion time (typ.) 320ms
Measurement error (25 °C) < ±6 K (voltage input < ±2 K; cold junction compensation < ±4 K)
Temperature coefficient < ±0.2 K/K
Sensor types Thermocouple K
Temperature range −100 … +1370 °C
Cold junction compensation at each pair of terminal blocks
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 65mA
Isolation 500 V system/field
Indicators LED (A, C) green: Function AI 1, AI 2; LED (B, D) red: Error AI 1, AI 2

NEW AND ORIGIN ITEM IN STOCK



WITH ONE YEAR WARRANTY



Hope anyone enquire from us,pls click this sales7@cambia.cn


Q&A

Q: Do you provide warranty for the goods?
A: Yes, we provide warranty for all the goods from us.

Q: Could you provide technology support?
A: We're in this field more than 12 years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.

Q: Do you keeps goods in stock or only trading?
A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.

Q: Does your goods are new and original ?
A: yes ,they are new and original.

❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍✨
