Honeywell 10208/2/1 Relay Output Module

Description：

The 10208/2/1 relay output module features ten potential-free relay contact output channels capable of driving loads up to 70 W. These loads can be resistive (e.g., lamps) or inductive (e.g., solenoids). For inductive loads, an external suppression diode must be mounted. The outputs are not tested and therefore should not be used for fail-safe applications. The maximum voltage on the relay contacts may be 36 Vdc to meet IEC 1010 standards. The outputs are also controlled by the watchdog, meaning the relays de-energize if the system shuts down and the watchdog switches off.

Technical Specifications：

• General

  • Type Number: 10208/2/1 11800
  • Approvals: CE, TÜV, UL
  • Software Versions: ≥ 3.00
  • Space Requirements: 4 TE, 3 HE (= 4 HP, 3U)

• Power

  • Power Requirements:
    • 5 Vdc, 25 mA
    • 24 Vdc, 120 mA

• Output

  • Number of Output Channels: 10
  • Output Specification: Relay Contact
  • Maximum Current: 2 A
  • Maximum Voltage: 30 Vac / 36 Vdc – IEC 1010 (1990), Overvoltage Category 3, Table D.12
  • Maximum Switched Power: 100 W / 1000 VA
  • Contact Material: Gold Flush Silver-Cadmium Oxide
  • WDG Input Current: 4 mA
