General Electric IC693CPU364 Central Processing Unit
SKU: IC693CPU364
In stock
Description

Specifications:

  • User Memory: Total of 240K Bytes. Actual available user program memory depends on the amounts configured for %R, %AI, and %AQ configurable word memory types.

  • Processor Speed: 25 MegaHertz.

  • Processor Type: 80386EX.

  • Ethernet Interface: Supports the 10BaseT (direct receiver) or AAUI (external transceiver) interfaces. Does NOT support auto-negotiation of half/full duplex.

  • Operating Temperature: 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) ambient.

  • Typical Scan Rate: 0.22 milliseconds per 1K of logic (boolean contacts).

  • Discrete Input Points (%I): 2,048.

  • Discrete Output Points (%Q): 2,048.

  • Discrete Global Memory (%G): 1,280 bits.

  • Internal Coils (%M): 4,096 bits.

  • Output (Temporary) Coils (%T): 256 bits.

  • System Status References (%S): 128 bits (%S, %SA, %SB, %SC - 32 bits each).

  • Register Memory (%R): Configurable in 128 word increments from 128 to 16,384 words with Logicmaster and from 128 to 32,640 words with Control version 2.21.

  • Analog Inputs (%AI): Configurable in 128 word increments from 128 to 16,384 words with Logicmaster and from 128 to 32,640 words with Control version 2.21.

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY
