GE PQMII-T20-C-A Power Quality Meter

Description:

The GE PQMII-T20-C-A meter is a high-performance power quality meter designed to provide accurate and reliable monitoring of electrical systems. It measures key parameters such as voltage, current, power, energy, and frequency, helping to ensure the efficient operation of electrical equipment and systems. With advanced features like harmonic analysis and waveform capture, this meter offers in-depth analysis for optimizing power quality and system reliability.

Specifications:

• Voltage Range: 20-60 VDC / 20-48 VAC, 50/60 Hz
• Power Rating: 20 VA
• Analog Input: One 4 to 20 mA analog input
• Output Relays: Four (4) output relays
• Switch Inputs: Four (4) switch inputs
• Isolated Analog Outputs: Four (4) isolated analog outputs
• Setpoints: Programmable for alarm or control functions

Features:

• Power Quality Monitoring: Measures voltage, current, power, energy, and frequency to ensure efficient system operation
• Event Recording: Captures and logs power quality events for analysis and troubleshooting
• Harmonic Analysis: Analyzes harmonics up to the 63rd order to detect potential power quality issues
• Waveform Capture: Records voltage and current waveforms for detailed analysis of disturbances
• Communication Protocols: Supports Modbus and DNP 3.0 for easy integration with SCADA and DCS systems
• User Interface: Features a keypad and a large illuminated display for intuitive setup, monitoring, and data visualization
