GE IS220UCSAH1A Mark VIe Embedded Controller Module

Specifications：

• Manufacturer: General Electric (GE)
• Series: Mark VIe
• Part Number: IS220UCSAH1A
• Functional Acronym: UCSA
• Functional Description: PAMC Acoustic Monitor (Processor)
• Instruction Manual: GEH-6725R
• PCB Coating: Conformal Coating
• Applications: Mark VIe, Mark VIes, EX2100e, LS2100e
• Functional Revision 1: A
• Product Type: Mark VIe Controller

Product Description：

The IS220UCSAH1A, manufactured by General Electric, serves as a Processor/Controller specifically designed for the Mark VI system. This system, part of GE's Speedtronic line, is tailored to manage gas or steam turbines efficiently. Equipped with an HMI (human machine interface) featuring CIMPLICITY graphics interface software, it's optimized for heavy-duty turbine operations.

The IS220UCSAH1A is housed within a single boxed component, featuring a front faceplate for easy communication connection, two screw mounts at the rear edge, and grill openings on three sides to facilitate airflow. Designed for base-mounting within a cabinet, up to three components can be mounted adjacent to each other for compact arrangements, facilitating triple redundant systems.

Operating on a QNX operating system, the IS220UCSAH1A is powered by a Freescale 8349, 667 MHz processor. It utilizes a power source rated at 18-36 V dc, consuming 12 watts. With a temperature range of 0 to 65 degrees Celsius, the board does not require a fan for cooling, even at maximum temperature. Suitable for NFPA Class 1, Div. 2 applications.

The front faceplate features six female jack connectors, a USB port, and multiple LED indicators. LED indicators along the left side include Link/Act, while a line of indicators in the middle indicates Power, Boot, Online, Flash, DC, and Diag statuses. Ethernet connections are facilitated via jack connectors, enabling communication with MKVI, MKVIe, or EX2100 excitation controls, maintenance stations, and operator stations.
