GE IS210BPPCH1AC Mark VIe I/O Pack Processor Card

Description

The IS210BPPCH1AC is an advanced I/O Pack Processor Board used in the GE Mark VIe Speedtronic system. It provides upgraded capabilities compared to the previous BPPB input and output packs. This board is suitable for both Dual and Triple Modular Redundant (TMR) configurations, offering flexibility for various system setups. The board is designed to support auto reconfiguration from BPPB to BPPC where applicable.

Specifications

• Manufacturer: General Electric
• Product ID: IS210BPPCH1AC
• Type: I/O Pack Processor Board
• System Compatibility: Mark VIe Speedtronic system
• Catalog Description: Internal UCPA Processor Board for Mark VIe

Features

• Diagnostic Signals to UCPA: ATTN
• Local CPU Power Supplies: Integrated
• Flashing Patterns Quantity: 7 for Red ATTN and 4 for Green ATTN
• LED Colors: Red and Green
• Manual: GEH-6721; Vol I, II, and III
• Model Type: Internal UCPA Processor
• Nominal Voltage Range: 9-16 VDC with 12 VDC nominal
• Processor Board Compatibility: YAICS1B, YDIAS1B, YDOAS1B, PVIBH1B, YVIBS1B, and more

Key Features:

• Reset Circuits: Includes hardware watchdog timer
• Status Indication LEDs: Red and Green ATTN LEDs
• Branding Support: ToolboxST application allows marking code sets for specific purposes
• System Compatibility: Can be used in Simplex, Dual, or TMR configurations within the Mark VIe Speedtronic system
