GE IS210AEPSG1AFC Power Supply Board

Description

The IS210AEPSG1AFC is a compact, rectangular-shaped power supply board, designed as part of the Mark VI series for managing heavy-duty steam or gas turbines. It integrates numerous components to regulate power, protect against voltage surges, and manage heat dissipation for reliable operation in demanding industrial environments.

Specifications

• Dimensions: 11 cm x 12.5 cm x 3 cm

• Weight: 0.24 kg

• Key Components:

  • Transformers, inductor coils
  • Power supply components
  • Varistor (voltage protection)
  • Metal film resistors, capacitors (polyester vinyl, ceramic, high-voltage electrolytic)
  • Transistors, stab-on connectors, plug connectors, header connectors
  • LED indicators, test points (TP) for diagnostics
  • Integrated circuits for advanced control

• Power Regulation: Equipped with transformers and inductor coils to ensure a stable and reliable power supply.

• Voltage Protection: Varistors protect against voltage surges, safeguarding components and extending lifespan.

• Heat Management: Transistors positioned near heat sinks for optimal heat dissipation, ensuring stable performance even under heavy loads.
