GE IS210AEPSG1A Power Supply Board

Technical Specifications:

• Manufacturer: GE Energy
• Series: Mark VIe Wind
• Part Number: IS210AEPSG1A
• Functional Acronym: AEPS
• Functional Description: AE Power Supply Board
• PCB Coating: Normal Coating
• Functional Revision 1: A

Product Description:

The IS210AEPSG1A is a PCB component designed specifically for the Mark VIe system from General Electric (GE) Energy. The Mark VIe turbine control system is designed for gas or steam turbine management and was one of the last systems released by GE Energy under the ‘Speedtronic’ line, which includes Ethernet communications capabilities.

The IS210AEPSG1A Power Supply Board regularly monitors the greater turbine assembly for issues such as vibration, shaft voltage build-up, flame detection, and temperature issues. It does this using both general-purpose Input/Outputs and application-specific I/Os. This board is considered a modified PCB version, as it exists as a daughter product to the preexisting IS210AEPSG1 General Electric product. It revises the original product through its inclusion of a singular functional revision, graded at an "A" rating.

 Specifications:

The IS210AEPSG1A is a power supply board component. This specific model is a small rectangular board that is very component-dense. The density of its components is supported by a number of standard-issued factory-drilled holes. Additionally, the board has factory-made drill marks in several places within its body.

For additional voltage and surge protection purposes, this board is built with transformers, a power supply, and an inductor coil. It also features four pairs of fuses of various sizes, with a separate line of four fuses existing near the left edge of the greater assembly.

The IS210AEPSG1A has resistors made of metal film and makes use of several metal-oxide varistor components, as well as capacitors made of ceramic material and polyester vinyl. It also features several high-voltage electrolytic capacitors located on its surface either grouped singularly or in pairs.
