GE IC694MDL340 OUTPUT MODULE

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone enquire from us,pls click this sales7@cambia.cn


► Product Description

The IC694MDL340 is a 120 VAC, 0.5 amp output module with 16 output points manufactured by GE Fanuc for the Rx3i PACSystem. The 16 points are in two groups of eight. Each group is powered by its own common, but the commons are distinct and not connected. Each group of the IC694MDL340 output module can be powered from the same supply or used in a different phase. Both groups are protected from potential power surges by a 3 amp fuse. Each output is also equipped with an RC snubber that eliminates noise that may exist on the power line.

This module provides a high degree of inrush current, which allows the outputs to control a variety of inductive and incandescent loads. Required AC Power to operate loads must be user-supplied. Individually numbered LEDs on the front of the IC694MDL340 module share valuable info such as output performance and blown fuses. The red LED labeled “F” turns ON if either of the fuses become non-functional. A load must be connected to the blown fuse for the LED indicator to emit status. Two red bands warn the user of high voltage danger. The IC694MDL340 module can be installed in any RX3i system I/O slot. Its power requirements are 315mA with all outputs ON powered by a 5 volt bus on the backplane. The module’s output voltage range is between 85 to 132 volts AC.
