GE IC200MDL240 Input Module

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone enquire from us,pls click this sales7@cambia.cn


► Product Description

IC200MDL240 is a VersaMax AC Input Module with positive logic or sourcing type inputs. This means the inputs will receive current from AC input devices and then return the current on the common. To accomplish this, input devices are connected between the input and common terminals. The IC200MDL240 provides two groups of eight discrete inputs. Power for this particular module is derived from the backplane with intelligent processing performed from the CPU or NIU. Each module comes standard with LED indicators for on/off state and to confirm the presence of backplane power.

Prior to installation of the IC200MDL240 module, all parts should be carefully inspected for damage. If damage is found, make note and request a replacement part. Placing a damaged unit into a CPU can cause additional problems. Wiring photos and instructions are available online. Users should note that if hot insertion is done improperly, other modules on the same backplane could be disrupted.

No derating is needed if mounted vertically; however, those used at 132 VAC do require derating, though not at 120 VAC. For isolation, the user input to logic and frame ground is at 250 VAC continuous or 1500 VAC for one minute. Input voltage for this module is 0 to 132 VAC and 120 VAC nominal. This includes on response time on 1 cycle maximum and off response time of two cycles maximum. Installers should note that this module carries an explosion hazard, and no components should be substituted.
