GE-Emerson IC693ALG392 8-Channel Analog Current-Voltage Output Module

GE IC693ALG392 is an 8-channel Analog Current/Voltage Output module compatible with the PACSystems RX3i and Series 90-30 programmable logic controllers (PLCs). Here are its key specifications:

Number of Channels: 8

Output Type: Selectable, single-ended 4-20mA, 0-20mA, 0-10VDC, or -10 to +10VDC

Resolution:

• 0.5 µA (1 LSB = 0.5 µA) for 4-20 mA

• 0.625 µA (1 LSB = 0.625 µA) for 0-20 mA

• 0.3125 mV (1 LSB = 0.3125 mV) for 0-10VDC and -10 to +10VDC

Update Rate: 8 milliseconds for all channels

Accuracy: ±0.1% of full scale

External Supply Voltage Range: 20 to 30 VDC

Internal Supply Voltage: 5 VDC from PLC backplane

Isolation: 500 VDC between channels and backplane

Dimensions: (H x W x D) 31.24 mm x 35 mm x 87.63 mm

Weight: 0.13 kg
