GE DS200TCCBG1B I/O TC2000 Analog Board

Technical Specifications：

• Manufacturer: GE General Electric
• Series: Mark V
• Part Number: DS200TCCBG1B
• Functional Description: Extended Analog I/O Board
• Functional Acronym: TCCB
• PCB Coating: Normal Coating
• Functional Revision 1: B

Product Description：

The General Electric I/O TC2000 Analog Board DS200TCCBG1B features one 80196 microprocessor and multiple PROM modules. It also contains one LED and 2 50-pin connectors. The LED is visible from the side view of the board. The IDs for the 50-pin connectors are JCC and JDD. The board is also populated with 3 jumpers. The jumpers have IDs printed on the surface of the board. The IDs are JP1, JP2, and JP3. When the original board is installed in the drive, the installer configures the board to best meet the requirements of the drive. The jumpers enable the installer to set the configuration values by changing the position of the jumpers. The default positions of the jumpers are used under most conditions and require no further action by the installer. However, in some situations the installer changes the position of the jumper based on the information available in the printed information provided with the board.
