Emerson EPRO CON041 Eddy Current Signal Converter

Specifications

• Measurement Range: 8 mm
• Accuracy: ±1%
• Output Signal: -4V to -20V (Supply Voltage Range: -23V to -32V)
• Power Supply: DC -23V to -32V
• Operating Temperature: -30°C to 100°C
• Weight: ~60 grams (2.12 oz)
• Frequency Range: 0 to 20,000 Hz
• Rise Time: < 15 µs

Features

• Non-contact Sensor: Measures radial and axial shaft displacement, position, eccentricity, and speed without contacting the measured surface.
• Dynamic Performance: Supports a wide frequency range of 0 to 20,000 Hz with a rise time of less than 15 µs.
• Environmental Resistance: Operates in harsh environments with a temperature range of -30°C to 100°C and protection class IP20.
• Shock and Vibration Resistant: Withstands 5g at 60 Hz at 25°C, ensuring stability in challenging conditions.
• Housing Material: Made from PA 6.6 for enhanced durability.
• Mounting: Din Rail mounting for easy installation.
• Connections: Screw terminals (max. 1.5mm² with wire-end sleeves).
• Compliance and Certifications: CE certified, complies with 2014/30/EU standards.
