Emerson Epro A6740 16-Channel Output Relay Module

Specifications

• Inputs: 60 inputs of type: channel clear, alert, and danger
• Outputs: Relay 1-16
• Time Delay: 0-30 seconds
• Handle: Easily removable card with a plate for module and sensor identification
• Dimensions (W x H x L): 60 mm x 128.4 mm x 160 mm
• Gross Weight: Approx. 450 g (0.992 lbs)
• Operating Temperature: 0 to 65°C (32 to 149°F)
• Storage Temperature: -40 to 70°C (-40 to 156°F)
• Relative Humidity: 5-95%, non-condensing
• Shock: 98 m/s² (9.98 g’s peak), 16 msec
• Vibration: 0.15 mm (10-55 Hz), 19.6 mm/s² (55-150 Hz)

Features

• Size: 3U, 2-slot plug-in module, reducing cabinet space requirements by half compared to traditional 6U size cards
• Compliance: API 670 compliant, hot-swappable module
• Inputs/Outputs: 60 inputs, 30 logical expressions, 16 relay outputs
• Compatibility: 6740 is a 12TE wide module for IMR6000 series rack
