Emerson DeltaV VE4005S2B1 Standard I/O Termination Block
SKU: VE4005S2B1
In stock
Description

Overview:

The EMERSON DeltaV VE4005S2B1 is a standard I/O termination block specifically designed for use with 8-channel, 4-20 mA HART I/O cards. This termination block provides a reliable interface for connecting field signals to the DeltaV automation system, ensuring secure and accurate signal transmission.

Key Features:

  • 8-Channel Configuration: Supports 8 channels for 4-20 mA HART signals.
  • Unique Keying Mechanism: Prevents incorrect card installation with a unique keying system consisting of two keying posts that rotate and lock into the terminal block base. Each post has 6 positions: A-F and 1-6.
  • Compatibility: Specifically keyed for the AI 8-Channel, 4-20 mA HART I/O card (Key: A1).
  • Compatible I/O Terminal Blocks:
    • Standard I/O Terminal Block
    • Fused I/O Terminal Block: Provides additional protection with fuses on each channel.
    • 4-Wire I/O Terminal Block: Supports 4-wire configurations for enhanced signal integrity.

Certifications:

  • CE: EMC: EN 61326-1
  • FM: FM 3600, FM 3611
  • CSA: CSA C22.2 No. 213, CSA C22.2 No. 1010-1
  • ATEX: EN60079-0, IEC60079-7, EN60079-15
  • IEC-Ex: IEC60079-0, IEC60079-7, IEC60079-15
  • Marine Certifications: IACS E10, ABS Certificate of Design Assessment, DNV Marine Certificate

Hazardous Area/Location:

  • FM (USA): Class I, Division 2, Groups A, B, C, D, T4
  • cFM (Canada): Class I, Division 2, Groups A, B, C, D, T4
  • ATEX: II 3G Ex ec IIC T4 Gc, II 3G Ex ec [ic] IIC T4 Gc, II 3G Ex nA nC IIC T4 Gc
  • IEC-Ex: II 3G Ex ec IIC T4 Gc, II 3G Ex ec ic IIC T4 Gc, II 3G Ex nA nC IIC T4 Gc

Installation Instructions: Refer to the following documents for detailed installation guidelines:

  • Class 1 Division 2 Installation Instructions: DeltaV M-series 12P1293
  • Zone 2 Installation Instructions: DeltaV M-series 12P2046

This streamlined overview focuses on the relevant specifications and features of the EMERSON DeltaV VE4005S2B1 Standard I/O Termination Block, specifically for 8-channel, 4-20 mA HART applications, while omitting unrelated product details.

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone enquire from us, please click this email: sales7@cambia.cn

Shipping

  • Delivery Port: Xiamen
  • FedEx Express, DHL Express International Shipping.

Packing & Delivery

  • 100% full New! - Original Factory Seal!
  • Warranty: 12 months globally!
  • Package: Original packing with cartons.

Payment

  • 100% T/T for stock items before shipping
