Emerson CON021+PR6426/010-130 Eddy Current Signal Converter

Description

The CON021+PR6426/010-130 is a high-precision sensor used to measure radial and axial shaft displacement, position, eccentricity, and speed in machinery. It is designed to provide accurate and reliable monitoring for early detection of potential issues, ensuring the safe and efficient operation of industrial equipment.

Specifications

• Frequency Range: 0 to 20,000 Hz
• Rise Time: < 15 µs
• Operating Temperature Range: -30°C to 100°C
• Supply Voltage Range: -23V to -32V (Output Range -4V to -20V)
• Shock and Vibration Resistance: 5g @ 60 Hz @ 25°C
• Protection Class: IP20
• Weight: ~120 grams (4.24 oz)
• Mounting: 4 Screws M5x20 (included in delivery)
• Connections: Self-locking Lemo-plug for transducer, Screw terminal type for supply/output

Features

• Dynamic Performance: Capable of handling high-frequency applications, ensuring fast and reliable measurements.
• High Accuracy: Provides precise displacement measurements with a sensitivity of 2 V/mm (50.8 mV/mil).
• Temperature Stability: Operates reliably across a wide temperature range, from -30°C to 100°C, making it suitable for harsh industrial environments.
• Overvoltage Protection: Safeguards the connected equipment from voltage spikes, enhancing system reliability.
• Certifications: CE, ATEX, IEC-Ex, CSA certified, suitable for use in hazardous areas.
