Bently Nevada 330103-06-25-10-02-00 3300 XL 8 mm Probe

3300 XL 8 mm Probe and Extension Cable Highlights

Design Improvements:

• TipLoc Molding: Enhanced bond between probe tip and body.
• CableLoc Design: Secure attachment with 330 N (75 lbf) pull strength.
• FluidLoc Option: Prevents oil and liquid leakage.

Specifications:

• Operational Range: +18 °C to +27 °C (+64 °F to +80 °F).
• Power Requirements: -17.5 Vdc to -26 Vdc without barriers; -23 Vdc to -26 Vdc with barriers.
• Sensitivity: < 2 mV change per volt change in input voltage.
• Output Resistance: 50 Ω.

Probe Resistance (RPROBE) Lengths and Resistances:

• 0.5m: 7.45 ± 0.50 Ω
• 1.0m: 7.59 ± 0.50 Ω
• 1.5m: 7.73 ± 0.50 Ω
• 2.0m: 7.88 ± 0.50 Ω
• 5.0m: 8.73 ± 0.70 Ω
• 9.0m: 9.87 ± 0.90 Ω

Extension Cable Resistance Lengths and Resistances:

• 3.0m: RCORE 0.66 ± 0.10 Ω, RJACKET 0.20 ± 0.04 Ω
• 7.5m: RCORE 1.65 ± 0.25 Ω, RJACKET 0.49 ± 0.10 Ω

Environmental Limits:

• Probe Temperature Range:
  • Standard: -51 °C to +177 °C (-60 °F to +351 °F)
  • Extended: -51 °C to +260 °C (-60 °F to +500 °F)
• Proximitor Sensor Temperature:
  • Operating: -51 °C to +100 °C (-60 °F to +212 °F)
  • Storage: -51 °C to +105 °C (-60 °F to +221 °F)
• Relative Humidity: <3% change in ASF with 93% humidity.

Hazardous Area Approvals:

• North America: Ex ia IIC T4/T5; Class I Zone 0; Class I Division 1.
• Europe: II 1 G EEx ia IIC T4/T5.

Ordering Information:

• Bently Nevada 330103 3300 XL 8 mm Probe, M10 x 1 thread, without armor
• Part Number: 330103-06-25-10-02-00
• Unthreaded Length Option: 06 = 60mm
• Overall Case Length Option: 25 = 250mm
• Total Length Option: 10 = 1.0 metre (3.3 feet)
• Connector and Cable-Type Option: 02 = Miniature coaxial ClickLocTM connector, standard cable
• Agency Approval Option: 00 = Not required

Materials:

• Probe Tip: Polyphenylene sulfide (PPS)
• Probe Case: AISI 303 or 304 stainless steel (SST)
• Weight: 0.323 kg
