Bently Nevada 128987-130-01-CN 3300 XL 8mm Proximity Transducer System
SKU: 128987-130-01-CN
In stock
Description

Description:

This system provides an output voltage directly proportional to the distance between the probe tip and the observed conductive surface. It can measure both static (position) and dynamic (vibration) values. The primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.

Features:

  • The 3300 XL 8 mm system offers the most advanced performance in eddy current proximity transducer systems.
  • The standard 3300 XL 8 mm 5-meter system fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability.
  • All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
  • Each 3300 XL 8 mm Transducer System component is backward-compatible and interchangeable with other non-XL 3300 series 5 mm and 8 mm transducer system components.
  • The 3300 XL Proximitor Sensor is highly immune to radio frequency interference, enabling installation in fiberglass housings without adverse effects from nearby radio frequency signals.

Specifications:

The following specifications are for a 3300 XL 8 mm Proximitor Sensor, extension cable, and 8 mm probe between +18˚C and +27˚C (+64˚F to +80˚F), at a maximum altitude of 2000 meters, with a -24 Vdc power supply, a 10 kΩ load, an AISI 4140 steel target, and a probe gapped at 1.27 mm (50 mils).

NEW AND ORIGINAL ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone inquires from us, please click this sales7@cambia.cn

  1. Lower your support costs.
  2. Provide on-going availability of automation replacement parts.

Quantity available: 10
Warranty: 12 months.

Technical specifications, manuals, and data sheets are available.

For inquiry details, please pay attention as below:

  • All quotes based on EXW only.
  • Shipping time: 5-7 days, via DHL/TNT/UPS/EMS/Fedex.
  • Payment terms: 100% T/T PAYMENTS before shipping.
