Bachmann GIO212 Universal Input/Output Module

Description

• Type: Universal Input/Output Module
• Channels: 12, individually configurable as input or output

Features

• Signal Types: Supports both analog and digital signals
• Analog Inputs:
  • Voltage: ±10 V to ±10 mV
  • Current: 0/4 to 20 mA
• Temperature Sensors:
  • Supports: Pt100/Pt1000 (2-, 3-, and 4-wire measurement)
  • Thermoelements: J, K, T, N, E, R, S, B
• Digital Inputs:
  • Voltage: 24 V
  • Counter: 32-bit, A and A/B operation
• Analog Outputs:
  • Voltage: ±10 V
  • Current: 0/4 to 20 mA
• Digital Outputs:
  • Current: 100 mA
  • Configurable as: Low-Side, High-Side, Push-Pull, PWM/frequency modulation
• Resolution:
  • Inputs: 16-bit
  • Outputs: 14-bit
• Filter: Adjustable from 4 kHz to 0.5 Hz per channel
• Status Display: Digital status display for analog channels
• Protection: Overload, short circuit, and external voltage-proof
• Isolation: Galvanic isolation from the system (500 V)
• Design: Condensation-proof ColdClimate design

Specifications

• Modes per Channel: Analog input, temperature measurement input, analog output, digital input
• Error Monitoring: Overload, overtemperature, and undervoltage of the supply
• Measuring Range Monitoring: Freely adjustable (±105%)
