Allen Bradley 1756-PAR2 ControlLogix Power Supply Module

Description

The 1756-PAR2 is a power supply module designed for the ControlLogix system, providing multiple DC output voltages to support various components within the control architecture. This module is engineered to deliver reliable power while accommodating a wide range of input voltages, ensuring stable operation in diverse industrial environments.

Specifications

• Input Voltage Range: 85-264V AC
• Nominal Input Voltage: 120/240 V AC
• Nominal Input Frequency: 50/60 Hz
• Output Voltages:
  • 5.1V DC @ 13A
  • 3.3V DC @ 4A
  • 1.2V DC @ 1.5A
  • 24V DC @ 2.8A
• Output Power: 75 Watts
• Operating Temperature Range: 0°C to 60°C (32°F to 140°F)
• Weight: Approximately 0.77 kg (1.7 lbs)
• Dimensions: 14.0 x 7.8 x 14.5 cm (5.51 x 3.07 x 5.71 in.)

Features

• Multiple Output Voltages: The module provides various DC output voltages to effectively power different components, facilitating versatility in control systems.
• Wide Input Voltage Range: The 1756-PAR2 can handle input voltage fluctuations between 85-264V AC, ensuring stable operation in varying conditions.
• High Output Power: With the capability of delivering up to 75 Watts, this power supply meets the demands of robust industrial applications.
• Compact Design: Its space-saving configuration makes it suitable for use in applications where space is at a premium.
• Robust Construction: Built to withstand the rigors of industrial environments, this module ensures durability and long-term performance.
