ABB RTU560 Remote Terminal Unit

Runto Electronic Automation Limited

Product Number

RTU560

ABB RTU560 is a remote terminal unit used for monitoring and controlling equipment and processes in power systems. The following is an introduction to its functions, working principles, and technical parameters:
1. Function:
-Monitoring and data collection: The RTU560 can monitor various devices and parameters in the power system, such as transformers, switches, currents, voltages, etc., and collect data for analysis and control.
-Remote control: This terminal unit can achieve remote control of the power system through communication with remote devices such as switches, circuit breakers, etc., including operations such as switches, regulation, and protection.
-Communication function: supports multiple communication interfaces and protocols, such as serial port, Ethernet, Modbus, etc., and can exchange and share data with other devices and systems.
-Alarm and Event Management: Equipped with alarm and event management functions, it can monitor abnormal situations in the system in real time, and provide alarms and records for timely processing and analysis.
-Data storage and transmission: Support the storage and transmission of data, which can store the collected data on local or remote servers, and achieve real-time transmission and sharing of data.
2. Working principle:
The RTU560 receives signals from devices and sensors in the power system, processes and controls them through connections. It communicates with other devices and systems to achieve data exchange and sharing, as well as remote monitoring and control of the power system.
3. Technical parameters:
-Communication interface: Supports multiple communication interfaces, such as serial port, Ethernet, etc.
-Working temperature range: usually between -40 ° C and 70 ° C.
-Power supply: usually 24V DC or 48V DC.
-Size and weight: The specific size and weight can vary depending on the specific model. Users can refer to the equipment's technical manual for detailed information.
