ABB 1SAP220600R0001 CI502-PNIO Interface Module

General Information:

• Extended Product Type: CI501-PNIO
• Product ID: 1SAP220600R0001
• ABB Type Designation: CI501-PNIO

Technical Specifications:

• Function: PROFINET IO RT device with:
  • Analog Inputs: 4 (U, I, RTD)
  • Analog Outputs: 2 (U, I)
  • Digital Inputs: 8 (24VDC)
  • Digital Outputs: 8 (24VDC, 0.5A)
• Input Voltage Type: DC
• Input Voltage (Uin): 24 V DC
• Input Current: 5 mA
• Delay Time (τ): 0.1 … 32 ms
• Output: Transistor
• Output Voltage Type: DC
• Output Current: 0.5 A
• Output Voltage Maximum: 20.4 … 28.8 V
• Degree of Protection: IP20
• Supply Voltage: 20.4 … 28.8 V DC

Physical Dimensions:

• Product Net Weight: 0.136 kg
• Product Net Depth / Length: 62 mm
• Product Net Height: 76 mm
• Product Net Width: 67.5 mm
• Gross Weight: 0.16 kg
• Package Level 1 Dimensions:
  • Depth / Length: 84 mm
  • Height: 72 mm
  • Width: 71 mm
  • Units per Carton: 1

Additional Information:

• Product Main Type: CI501
• Product Name: Distributed Automation I/Os
• Made To Order: No
• Minimum Order Quantity: 1 piece
• Order Multiple: 1 piece
• Selling Unit of Measure: piece
• eClass: 27-24-26-07
• ETIM 8: EC001604 - Fieldbus, decentr. periphery - communication module
• UNSPSC: 32151705
• SCIP: a307b9ae-b352-4d4d-8ebf-99c63e467033 Germany (DE)
• WEEE B2C / B2B: Business To Business
• WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
