Woodward 8200-1302 Digital Governor Turbine
Jul. 7, 2023
Jul. 7, 2023
Technical Specifications
Analog Input : 4-20 mA channels (with Loop Power)
EMC Immunity : EN 61000-6-2
Enclosure Type : IACS UR E10 (Commercial Marine)
Features : ATEX, IP-54, and Pollution Degree 3
Input Voltage : LV 18-36 VDC isolated
Operating Temperature : -22 - 158 F
Screen Size : 8.4in LCD
Storage Temperature : -22 - 158 F
Product Description
The 8200-1302 is one of several Woodward 505 Digital Governors available for the control of steam turbines. This operator control panel acts as a graphical interface and keypad that allows for adjustments to and communication with the turbine. This can be configured through Modbus communication ports located on the unit.
The 8200-1302 has multiple features available:
Auto start sequencing for hot and cold starts, with temperature input options
Critical speed avoidance on three-speed bands
Ten external alarm inputs
Ten external DI trip inputs
Trip indication for Trip and Alarm events with associated RTC time stamp
Dual Speed and Load Dynamics
Peak Speed Indication for Overspeed Trip
Zero Speed Detection
Remote droop
Frequency dead-band
The unit also offers three normal operating modes, including configuration,
operation, and calibration modes.
The unit includes two redundant speed inputs that can accept magnetic pickup units, eddy current probes, or proximity probes. It has analog inputs (8) that can be configured for any of twenty-seven functions. The unit also has an additional twenty contact inputs. The first four of these contacts default for shutdown raise speed setpoint, reset, and lower speed set point. The others
can be configured as needed. Additionally, the unit has two 4-20 mA control
outputs and eight Form-C relay contact outputs.
