Triconex 8312 Power Supply Module
May 26, 2023
May 26, 2023
Each Tricon chassis is equipped with two Power Modules—either one is fully capable of running the Tricon at full load and rated temperature. Each Power Module can be replaced online. The Power Modules, located on the left side of the chassis, convert line power to DC power appropriate for all Tricon modules. Terminal strips for system grounding, incoming power and hard-wired alarms are located on the lower left corner of the backplane. Incoming power should be rated for a minimum of 240 watts per power supply.The Power Module alarm contacts are actuated when:
• A module is missing from the system
• The hardware configuration conflicts with the control program’s logical
configuration
• A module fails
• A Main Processor detects a system fault
• Primary power to a Power Module fails
• A Power Module has a “Low Battery” or “Over Temperature” warning
Power Module Specifications
Isolation : >1,000 VAC or 1,500 VDC, Input to Output
Input Terminations : Protected by safety cover
Accepts three 12-gauge wires (3.310mm2): neutral, hot, and protective earth (chassis ground)
Over-Temp. Sensor : Temperature warning monitor—trips when internal temp. is greater than 181° F (83°C); this typically occurs at ambient temperature 140°F (60°C) or higher
Alarm Contacts : Normally open, normally closed and common Each contact supports
120 VAC @ 1 amp Accepts 12-gauge (3.310mm2) wire Protected by safety
cover
Input Power Required : 240 watts minimum per Power Module
Output Power : 175 watts at 140°F (60°C)
Output Voltage : 6.5 VDC, ±1% under all operating conditions
Output Current : 27 amps maximum at 140°F (60°C) ambient
