The 3300 XL Proximitor Sensor incorporates numerous improvements over previous designs. Its physical packaging allows you to use it in high-density DIN-rail installations. You can also mount the sensor in a traditional panel mount configuration, where it shares an identical 4-hole mounting “footprint” with older Proximitor Sensor designs. The mounting base for either option provides electrical isolation and eliminates the need for separate isolator plates. The 3300 XL Proximitor Sensor is highly immune to radio frequency interference, allowing you to install it in fiberglass housings without adverse effects from nearby radio frequency signals. The 3300 XL Proximitor Sensor’s improved RFI/EMI immunity satisfies European CE mark approvals without requiring special shielded conduit or metallic housings, resulting in lower installation costs and complexity.
The 3300 XL’s SpringLoc terminal strips require no special installation tools and facilitate faster, more robust field wiring connections by eliminating screw-type clamping mechanisms that can loosen.
Proximitor Sensor Temperature Range
Operating Temperature: -51 °C to +100 °C (-60 °F to +212 °F)
Storage Temperature: -51 °C to +105 °C (-60 °F to +221 °F)
Relative Humidity: Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity in accordance with IEC standard 68-2-3 for up to 56 days.
Patents: Components or procedures described in one or more of the following patents apply to this product: 5,016,343; 5,126,664; 5,351,588; and 5,685,884.
Ordering Information Proximitor Sensor
3300 XL Proximitor Sensor
330180-AXX-BXX
A: Total Length and Mounting Option
1 0 1.0 metre (3.3 feet) system length, panel mount
1 1 1.0 metre (3.3 feet) system length, DIN mount
1 2 1.0 metre (3.3 feet) system length, no mounting hardware
5 0 5.0 metre (16.4 feet) system length, panel mount
5 1 5.0 metre (16.4 feet) system length, DIN mount
5 2 5.0 metre (16.4 feet) system length, no mounting hardware
9 0 9.0 metres (29.5 feet) system length, panel mount
9 1 9.0 metres (29.5 feet) system length, DIN mount
9 2 9.0 metres (29.5 feet) system length, no mounting hardware
B: Agency Approval Option
0 0 Not required
0 5 CSA, ATEX, IECEx approvals
1. Mounting option “A”, Options –50 or -90
Figure 19: Panel Mount 3300 XL Proximitor Sensor
1.Mounting option “A”, Options –51 or –91
2.35mm DIN rail (not included)
3.89.4 mm (3.52 in). Additional 3.05 mm (0.120 in) clearance required to remove DIN rail.
Figure 20: DIN Mount 3300 XL Proximitor Sensor
